Description
50Nm Torque, 320W Power, 320Wh Battery
With its unmatched combination of lightweight, ride quality, and supernatural amplification, the Levo SL delivers the best ride, amplified. Compare it to anything out there, with a motor or without, and we think you’ll agree—Levo SL is The Ultimate Trail Bike.
IT’S ALL ABOUT THE RIDE: When everything works just right, a bike disappears beneath you. We stripped away the mass to keep the Levo SL lean and responsive. It’s tough enough to withstand heavy abuse, but light enough to flick through a rock garden. Its dialed geometry, kinematics, and shock tuning work together as one to deliver control, confidence and precision beyond compare.
THE MAGIC CARPET RIDE: GENIE Our patent-pending GENIE technology is the ultimate air spring. It combines the control-enhancing linear spring rate of a coil spring through the “bump zone” with the progressive spring rate of an air spring at the end of the stroke to avoid bottom-outs.
GEOMETRY OF CONTROL: The Levo SL geometry delivers an exceptional ride right out of the box, combining big-bike capability with a nimble feel in tight sections. A refined reach centers you on the bike for optimal traction and cornering, while the low bottom bracket, slack head angle, and optimized fork offset ensure stability on rough terrain. Riders who want to can easily personalize the six-way adjustable geometry to match their style and terrain.
MIXED WHEEL: A 29” front wheel helps ensure stability and surefooted performance in the most hectic terrain, while a 27.5” rear wheel allows for a short chainstay and super responsive behavior. If you prefer the rolling and traction benefits of a 29” rear wheel, just flip the pivot link chip and mount the big wheel.
TURBO OPERATING SYSTEM: Our seamlessly integrated operating system delivers unmatched performance across torque, range, ride feel, ride quality, power, reliability, and rider experience. It’s the invisible hand that enables you to do more, know more, go farther, feel stronger, and have more fun.
SPECIALIZED SL 1.2 MOTOR: Meet the Specialized SL 1.2 motor: it delivers 43% more torque (50Nm) and 33% more power (320 Watts) than its predecessor. Thanks to its unmatched efficiency, nothing beats its range-to-weight ratio. Paired with a seamless 320Wh battery pack, the Levo SL ensures supernatural amplification for up to 5 hours in Eco Mode. Extend your ride with our 160Wh Range Extender (sold separately), fitting snugly into your bottle cage for an extra 50% range.
IT’S ALL CONNECTED: MasterMind TCU, our advanced e-bike control unit, seamlessly connects with Turbo OS and the Specialized App. Adjust power levels with MicroTune. Over-the-air updates ensure that your bike gets better over time. The Levo SL integrates fully with the Specialized App, offering personalized motor settings and advanced security features like Smart Control and Turbo System Lock.
Traverse HD Wheels - The strongest, best riding carbon wheelset on the mountain
FOX 36 FLOAT X2 Fork - The most tunable, smoothest, descent-focused damper created by FOX
SRAM Maven Silver with HS2 Rotor - High performance power braking and heat dissipation
Bike Yoke Revive Max Dropper - Extremely short stack height, short overall length, very smooth
Specifications
E-Bike
- Wiring Harness: Custom Specialized wiring harness
- Charger: Custom charger, 48V System w/ SL system charger plug
- Motor: Specialized 1.2 SL Custom RX Trail Tuned Motor, 50Nm power, 320W power
- UI/Remote: Specialized MasterMind TCU, percentage of remaining charge, 120 possible display configurations, MicroTune assist adjustment, ANT+/Bluetooth®, w/Handlebar remote
- Battery: Specialized SL1-320, fully integrated, 320Wh
Frameset
- Seat Binder: Alloy, 38.6mm
- Frame: Levo SL carbon Frame, Fact 11m carbon, alloy shock extension, 150mm travel, adjustable head angle, BB height, and compatible with 27.5 or 29" wheels
Suspension
- Fork: Fox 36 Factory series, 29", Grip X2 damper, Kashima, S1: 150mm, S2-S6: 160mm
- Rear Shock: FOX FLOAT X Factory with Specialized GENIE Shock Tech, Ride Dynamics Trail Tune, 2-position lever w/3 setting Open mode tuning range, LSR adjustment, S2-S6:210x55mm, S1: FOX FLOAT Factory 210x52.5mm
Brakes
- Front Brake: SRAM Maven Silver, 4-piston caliper, hydraulic disc, 200mm HS2 Rotor
- Rear Brake: SRAM Maven Silver, 4-piston caliper, hydraulic disc, 200mm HS2 Rotor
Drivetrain
- Chain: SRAM X0 Eagle Transmission Flattop Chain
- Chainrings: SRAM T-type ring, 32t
- Cassette: SRAM X0 Eagle Transmission Cassette, 12spd, 10-52t
- Shift Levers: SRAM AXS POD Controller
- Crankset: SRAM X0 Eagle Crankset, 32T ring, Integrated Guard, 55mm Chainline, 165mm
- Rear Derailleur: SRAM X0 Eagle Transmission Derailleur
Wheels & Tires
- Front Tire: Butcher, GRID TRAIL casing, GRIPTON® T9 compound, 2Bliss Ready, 29x2.3"
- Rear Tire: Eliminator, GRID GRAVITY casing, GRIPTON® T9/T7 compound, 2Bliss Ready, 27.5x2.3"
- Inner Tubes: Standard, Presta Valve
- Front Wheel: Roval Traverse HD 29", DT Swiss 350, 15x110mm, 28h
- Rear Wheel: Roval Traverse HD 27.5", DT Swiss 350, XD freehub body, 12x148mm, 28h
Cockpit
- Grips: Deity Grips
- Handlebars: RaceFace Era Carbon, riser bar, 5-degree upsweep, 8-degree backsweep, S2:20mm Rise, S3-S6:40mm Rise, 800mm
- Saddle: Specialized Bridge Expert Mimic, hollow ti rail
-
SeatPost: Bike Yoke, Revive Max, 34.9
- S1: 125mm
- S2: 160mm
- S3-S4: 185mm
- S5-S6: 213mm
-
Stem: Industry 9 A35 stem, 40mm length, 35mm clamp diameter
Accessories
- SWAT: SWAT CC steerer tube integrated tool with chain tool and link
Product Details
- Product ID: 277411
- Compliance Certification: As applicable, certified to UL 2849 (e-system) and/or UL 2271 (battery) by UL Solutions and/or SGS. For information on lithium-ion battery standards and regulations in New York City, visit: NYC FDNY Batteries
Weight
- Weight: 18.18 kg (40 lb, 1.3 oz)
- Weight Size: S4
Weights based on production painted frames as pictured. Actual weights will vary based on colorway, frame size, and component variation. Specifications are subject to change without notice.
Geometry
| S1 | S2 | S3 | S4 | S5 | S6 | |
| Crank Length | 165 | 165 | 165 | 165 | 165 | 165 |
| Handlebar Width | 800 | 800 | 800 | 800 | 800 | 800 |
| Stem Length | 40 | 40 | 40 | 40 | 40 | 40 |
| Saddle Width | 155 | 155 | 143 | 143 | 143 | 143 |
| Seatpost Length | 125 | 125 | 160 | 185 | 213 | 213 |
| Stack | 609 | 617 | 626 | 635 | 645 | 654 |
| Reach | 405 | 425 | 445 | 470 | 495 | 525 |
| Head-Tube Length | 95 | 100 | 110 | 120 | 130 | 140 |
| Head-Tube Angle | 64.6 | 64.6 | 64.6 | 64.6 | 64.6 | 64.6 |
| B-B Height | 343 | 348 | 348 | 348 | 348 | 348 |
| B-B Drop | -34 | -29 | -29 | -29 | -29 | -29 |
| Trail | 132 | 132 | 132 | 132 | 132 | 132 |
| Fork Length, Full | 560 | 570 | 570 | 570 | 570 | 570 |
| Fork Rake/Offset | 42 | 42 | 42 | 42 | 42 | 42 |
| Front-Center | 726 | 752 | 776 | 806 | 835 | 869 |
| Chain-Stay Length | 433 | 432 | 432 | 432 | 432 | 432 |
| Wheelbase | 1158 | 1184 | 1208 | 1238 | 1267 | 1301 |
| Top Tube Length, Horizontal | 560 | 582 | 604 | 631 | 659 | 691 |
| Bike Stand-Over Height | 727 | 763 | 766 | 767 | 773 | 778 |
| Seat-Tube Length | 385 | 385 | 405 | 425 | 445 | 465 |
| Seat-Tube Angle | 75.8 | 75.8 | 75.8 | 75.8 | 75.8 | 75.8 |
